Laser Jewelry Spot Welder
KYG0787
Laser Spot Welding Machine
Laser spot welder with camera and microscope, designed for fine jewelry and micro-metal welding.
Welding, Laser & Engraving
Specifications
| Input Voltage | AC220V ± 10% 50HZ |
|---|---|
| Laser Continuously Adjustable | 1.0~15Hz Continuously Adjustable |
| Pulse Width | 0.1~10ms Grading Is Adjustable |
| Spot Adjustment Range | ± 3.0mm |
| Maximum Laser Power | 150W |
| Maximum Laser Pulse Energy | 40J |
| Power Consumption of Main Engine | ≤2KW |
| Aiming and Positioning | Built-in Camera System and Microscope |
| Ambient Temperature | ≤40℃ |
| Cooling Mode | Air Cooling |
| Control Mode | Touch Control |
| Laser Wavelength | 1064nm |
| Display Touch Screen Size | 7寸 (inches) |
| Volume | L525 x W307 x H413mm |
| Machine Weight | 26KG |
Overview
Highlights
- Integrated camera and microscope for detailed visual control
- Compact, air-cooled design minimizes workshop space use
- Touchscreen simplifies control for efficient workflow
Applications
- Jewelry spot welding (gold, silver, stainless steel)
- Ornamental micro-welds
- Fine assembly metal part joining
Overview
This laser spot welding machine is specially engineered for meticulous jewelry and micro-metal welding tasks. Its built-in camera and microscope support detailed observation and enhanced accuracy with every weld. The compact, air-cooled structure is optimized for small workshops or tight workspaces, cutting down on both required space and maintenance demands.
An intuitive touch screen control enables swift adjustments, ensuring operator comfort and efficiency during repetitive tasks.
Typical uses
- Spot welding jewelry items like gold, silver, and steel
- Creating intricate ornamental micro-welds
- Joining delicate metal parts in fine assemblies
