←Back to product range
Cleaning & Surface Treatment
Ultrasonic Cleaner
KYG0449
DR-P Series Digital Ultrasonic Cleaner
Digital ultrasonic cleaners with advanced controls and stable, efficient cleaning performance.
Configure enquiry
Select model
Model: DR-P20
Parameter comparison
Model parameter comparison
Compare DR-P20, DR-P30, DR-P40, and DR-P60.
Small screens show the selected variant first. Swipe the variant chips to switch.
Selected model
DR-P20
KYG0449-DR-P20
| Capacity | 2L |
|---|---|
| Heating Power | 100W |
| Ultrasonic Power | 160W |
| Inner Groove Size | 150*138*100mm |
| Outline Dimension | 178*165*220mm |
| Packing Size | 250*260*300mm |
| Weight | 2.5kg |
| Drain Valve | 无 |
| Vibrating Head | 2个 |
Selected model
DR-P30
KYG0449-DR-P30
| Capacity | 3L |
|---|---|
| Heating Power | 150W |
| Ultrasonic Power | 160W |
| Inner Groove Size | 240*138*100mm |
| Outline Dimension | 270*160*220mm |
| Packing Size | 350*250*310mm |
| Weight | 3.2kg |
| Drain Valve | 无 |
| Vibrating Head | 2个 |
Selected model
DR-P40
KYG0449-DR-P40
| Capacity | 4L |
|---|---|
| Heating Power | 220W |
| Ultrasonic Power | 160W |
| Inner Groove Size | 300*150*100mm |
| Outline Dimension | 325*175*240mm |
| Packing Size | 420*300*350mm |
| Weight | 3.8kg |
| Drain Valve | 无 |
| Vibrating Head | 2个 |
Selected model
DR-P60
KYG0449-DR-P60
| Capacity | 6L |
|---|---|
| Heating Power | 270W |
| Ultrasonic Power | 240W |
| Inner Groove Size | 300*150*150mm |
| Outline Dimension | 330*180*300mm |
| Packing Size | 420*300*400mm |
| Weight | 4.8kg |
| Drain Valve | 无 |
| Vibrating Head | 3个 |
Selected model
DR-P100
KYG0449-DR-P100
| Capacity | 10L |
|---|---|
| Heating Power | 310W |
| Ultrasonic Power | 320W |
| Inner Groove Size | 300*240*160mm |
| Outline Dimension | 330*270*320mm |
| Packing Size | 430*360*420mm |
| Weight | 5.2kg |
| Drain Valve | 有 |
| Vibrating Head | 4个 |
Selected model
DR-P130
KYG0449-DR-P130
| Capacity | 13L |
|---|---|
| Heating Power | 420W |
| Ultrasonic Power | 400W |
| Inner Groove Size | 300*240*200mm |
| Outline Dimension | 330*270*340mm |
| Packing Size | 430*360*450mm |
| Weight | 6.5kg |
| Drain Valve | 有 |
| Vibrating Head | 5个 |
Selected model
DR-P150
KYG0449-DR-P150
| Capacity | 15L |
|---|---|
| Heating Power | 470W |
| Ultrasonic Power | 480W |
| Inner Groove Size | 325*300*150mm |
| Outline Dimension | 350*330*350mm |
| Packing Size | 450*420*420mm |
| Weight | 7.5kg |
| Drain Valve | 有 |
| Vibrating Head | 6个 |
Selected model
DR-P200
KYG0449-DR-P200
| Capacity | 20L |
|---|---|
| Heating Power | 470W |
| Ultrasonic Power | 480W |
| Inner Groove Size | 325*300*200mm |
| Outline Dimension | 350*330*400mm |
| Packing Size | 460*420*420mm |
| Weight | 8kg |
| Drain Valve | 有 |
| Vibrating Head | 6个 |
Selected model
DR-P220
KYG0449-DR-P220
| Capacity | 22L |
|---|---|
| Heating Power | 470W |
| Ultrasonic Power | 480W |
| Inner Groove Size | 500*300*150mm |
| Outline Dimension | 530*330*350mm |
| Packing Size | 640*420*450mm |
| Weight | 8.75kg |
| Drain Valve | 有 |
| Vibrating Head | 6个 |
Selected model
DR-P360
KYG0449-DR-P360
| Capacity | 36L |
|---|---|
| Heating Power | 620W |
| Ultrasonic Power | 680W |
| Inner Groove Size | 500*300*200mm |
| Outline Dimension | 530*330*360mm |
| Packing Size | 640*420*450mm |
| Weight | 10kg |
| Drain Valve | 有 |
| Vibrating Head | 8个 |
Selected model
DR-P450
KYG0449-DR-P450
| Capacity | 45L |
|---|---|
| Heating Power | 1000W |
| Ultrasonic Power | 1280W |
| Inner Groove Size | 500*300*300mm |
| Outline Dimension | 600*440*530mm |
| Packing Size | 640*420*530mm |
| Weight | 30kg |
| Drain Valve | 有 |
| Vibrating Head | 16个 |
Selected variant
DR-P20
The selected variant stays on the left. Pick one more variant to compare side by side.
Selected variant
DR-P20
Compare variant
DR-P30
Heating Power
DifferentSelected variant
Compare variant
Ultrasonic Power
DifferentSelected variant
Compare variant
Inner Groove Size
DifferentSelected variant
Compare variant
Outline Dimension
DifferentSelected variant
Compare variant
Packing Size
DifferentSelected variant
Compare variant
Weight
DifferentSelected variant
Compare variant
Drain Valve
DifferentSelected variant
Compare variant
Vibrating Head
DifferentSelected variant
Compare variant
These two variants do not differ across the visible parameters.
View full comparison table
| Parameter comparisonModel | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Capacity | 2L | 3L | 4L | 6L | 10L | 13L | 15L | 20L | 22L | 36L | 45L |
| Heating Power | 100W | 150W | 220W | 270W | 310W | 420W | 470W | 470W | 470W | 620W | 1000W |
| Ultrasonic Power | 160W | 160W | 160W | 240W | 320W | 400W | 480W | 480W | 480W | 680W | 1280W |
| Inner Groove Size | 150*138*100mm | 240*138*100mm | 300*150*100mm | 300*150*150mm | 300*240*160mm | 300*240*200mm | 325*300*150mm | 325*300*200mm | 500*300*150mm | 500*300*200mm | 500*300*300mm |
| Outline Dimension | 178*165*220mm | 270*160*220mm | 325*175*240mm | 330*180*300mm | 330*270*320mm | 330*270*340mm | 350*330*350mm | 350*330*400mm | 530*330*350mm | 530*330*360mm | 600*440*530mm |
| Packing Size | 250*260*300mm | 350*250*310mm | 420*300*350mm | 420*300*400mm | 430*360*420mm | 430*360*450mm | 450*420*420mm | 460*420*420mm | 640*420*450mm | 640*420*450mm | 640*420*530mm |
| Weight | 2.5kg | 3.2kg | 3.8kg | 4.8kg | 5.2kg | 6.5kg | 7.5kg | 8kg | 8.75kg | 10kg | 30kg |
| Drain Valve | 无 | 无 | 无 | 无 | 有 | 有 | 有 | 有 | 有 | 有 | 有 |
| Vibrating Head | 2个 | 2个 | 2个 | 3个 | 4个 | 5个 | 6个 | 6个 | 6个 | 8个 | 16个 |
Specifications
| Voltage | AC110V-120V/60Hz; AC220V-240V/50Hz |
|---|---|
| Temperature Control | ≤80°C |
| Time Control | 1-60min |
| Control Panel | Touch buttons and mechanical knobs |
Overview
Highlights
- Reliable digital controls for consistent and repeatable cleaning results.
- Flexible degas and sweep modes adapt to a range of cleaning tasks.
- Wide choice of capacities from 2L to 45L matches diverse operational needs.
Applications
- Laboratory instrument cleaning
- Medical device sterilization
- Jewelry and watch maintenance
Overview
The DR-P Series digital ultrasonic cleaner harnesses third-generation circuit technology for superior, stable cleaning. Its advanced phase tracking and automatic frequency matching ensure consistent ultrasonic output, even during prolonged and demanding tasks. This makes the DR-P Series an ideal choice for users who require reliable deep cleaning with minimal manual adjustment.
User-friendly control via touch buttons and mechanical knobs, precise temperature regulation up to 80°C, and special functions like degassing, pulse, and sweep modes enable adaptability for various cleaning challenges. Designed for both efficiency and safety, the DR-P Series stands out with robust performance across multiple sizes to suit everything from delicate jewelry to intricate laboratory instruments.
Typical uses
The DR-P Series is commonly used in laboratories, healthcare facilities for medical device care, and professional maintenance of intricate components, such as watches and fine jewelry.
